• NTN KR19FLLD0H/L588 Hex Head Crowned Cam Follower 19x11x8mm M8X1.25 Thread
1 1

SKU: KR19FLLD0H/L588-NTN

NTN KR19FLLD0H/L588 Hex Head Crowned Cam Follower 19x11x8mm M8X1.25 Thread

NTN KR19FLLD0H/L588 Hex Head Crowned Cam Follower 19x11x8mm M8X1.25 Thread
€28,42 ex VAT
€28,42 ex VAT
Sale Sold out

In stock

Price Break
3+ €21,60
4+ €20,39
9+ €20,14
19+ €19,90
49+ €19,66
99+ €19,42
499+ €18,20
999+ €17,96
1999+ €17,72
2999+ €17,47
4999+ €16,99

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
X7DE3XI9GP
Brand / Quality:
NTN - High Quality
Outside Diameter:
19mm
Width:
11mm
Pitch:
M8X1.25
Technical
D - Outside diameter 19mm
d1 - Stud diameter 8mm
C - Outer ring width 11mm
F - Under roller diameter 10mm
B - Bearing / Inner ring width 12mm
B1 - Total stud length 32mm
B2 - Stud rod length 20mm
G - Stud thread designation M8X1.25
G1 - Thread length 10mm
C1 - Distance between roller and washer face 0.6mm
e - Inlet diameter 14mm
h - Hexagonal hole diameter 4mm
R - Track roller radius 500mm
Maximum tightening torque 8 n-m
Bearing with/without cage With
Radial clearance class CN
Precision class P0
Cr - Dynamic load rating 4.75 kN
C0r - Static load rating 5.4 kN
Track load capacity 1.38 kN
N - Grease lubrication limit speed 10000 tr/min
Tmin - Minimum operating temperature -20 Deg C
Tmax - Maximum operating temperature +100 Deg C
