• NTN M-UCFL207D1 Metric Two Bolt Oval Cast Iron Flange Housing with 35mm Bore Insert - Allow 2-3 Days
1 1

SKU: M-UCFL207D1-NTN

NTN M-UCFL207D1 Metric Two Bolt Oval Cast Iron Flange Housing with 35mm Bore Insert - Allow 2-3 Days

NTN M-UCFL207D1 Metric Two Bolt Oval Cast Iron Flange Housing with 35mm Bore Insert - Allow 2-3 Days
€36,82 ex VAT
€36,82 ex VAT
Sale Sold out

In stock

Price Break
3+ €27,98
4+ €26,41
9+ €26,10
19+ €25,78
49+ €25,47
99+ €25,15
499+ €23,58
999+ €23,27
1999+ €22,95
2999+ €22,64
4999+ €22,01

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
UCFL200_DESC
Brand / Quality:
NTN - High Quality
Inside Diameter:
35mm
Style:
UCFL
Bolt Hole Centres:
130mm
Technical
--- Dimensions
Shaft diameter 35mm
H 161mm
J 130mm
A<sub>2</sub> 19mm
A<sub>1</sub> 15mm
A 34mm
N 16mm
L 90mm
A<sub>0</sub> 44.4mm
B 42.9mm
S 17.5mm
Fixing bolt M14
--- Load rating
Dynamic load C<sub>r</sub> 28.4 kN
Static load C<sub>0r</sub> 15.3 kN
Fatigue load limit C<sub>u</sub> 1.09 kN
--- Unit information
Mass 1.2 kg
