RHP MSF3-3/16 Imperial Four Bolt Square Cast Iron Flange Housing and 3-3/16 inch Bore Grub Screw Insert
RHP MSF3-3/16 Imperial Four Bolt Square Cast Iron Flange Housing and 3-3/16 inch Bore Grub Screw Insert
Regular price
€454,42
ex VAT
Regular price
Sale price
€454,42
ex VAT
In stock
Price Break
10+
€345,34
20+
€325,94
30+
€322,06
40+
€318,18
50+
€314,30
75+
€310,42
100+
€291,01
200+
€287,13
250+
€283,25
500+
€279,37
1000+
€271,61
Quantity
Couldn't load pickup availability
Share this product
Description
Description
|
RHP MSF Series Heavy Duty 4 Bolt Square Cast Iron Housings: Bearing units supplied with a full width sealed heavy duty bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has two grub screws to allow tightening against the shaft after installation. |
- Brand / Quality:
- RHP - High Quality
- Inside Diameter:
- 80.96mm = 3.187 (3-3/16) inch
- Style:
- MSF
- Bolt Hole Centres:
- 171.45mm = 6.75 inch
Technical
Technical
| Bore | 3-3/16 inch |
|---|---|
| L | 8.406 inch |
| H | 7.244 inch |
| J | 6.75 inch |
| G | 0.75 inch |
| A | 2.138 inch |
| A1 | 3.529 inch |
| A4 | 1.024 inch |
| B | 3.375 inch |
| s | 1.346 inch |
| d1 | 4.174 inch |
| Dynamic load cr | 83000 N |
| Static load Cor | 64000 N |
| Rec max speed | 2000 rpm |
| Weight | 11.1 kg |
| Insert | <a href="advanced_search_result.php?keywords=1085-3-3/16G+insonly">1085-3-3/16G Click Here</a> |
| Casting group | 11 |
| Grease nipple thread | 1/4 UNF, 1/4 inch x 28 TPI |
