SKU: NJ1064MA/C3-SKF
SKF NJ1064MAC3 Single Row Cylindrical Roller Bearing with Brass Cage 320x480x74mm
SKF NJ1064MAC3 Single Row Cylindrical Roller Bearing with Brass Cage 320x480x74mm
Out of stock
Description
Description
|
SKF NJ Series Single Row Cylindrical Roller Bearings: The outer ring of this type has two integral flanges around which the cage and rollers are assembled, the inner raceway has a single flange permitting the ease of assembly but limiting axial location to one direction. Benefits: Axial location, ease of assembly and fitting |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 320mm
- Outside Diameter:
- 480mm
- Width:
- 74mm
- Seals / Shields:
- None
- Clearance:
- C3
Technical
Technical
| d | 320mm |
|---|---|
| D | 480mm |
| B | 74mm |
| Dynamic load C | 880 kN |
| Static load Co | 1430 kN |
| Fatigue load limit Pu | 132 kN |
| Reference speed | 1400 rpm |
| Limiting speed | 1900 rpm |
| Weight | 49 kg |
| d1 | 376mm |
| D1 | 422mm |
| F,E | 360mm |
| r1r2 min | 4mm |
| r3r4 min | 4mm |
| S | 9.7mm |
| da min | 335mm |
| da max | 355mm |
| db | 380mm |
| Da max | 465mm |
| ra max | 3mm |
| rb max | 3mm |
| kr | 0.1 |
| Angle ring | HJ1064 |
| Angle ring weight | 5.65 kg |
| B1 | 19mm |
| B2 | 36mm |
