SKU: NNCL4852CV-SKF
SKF NNCL4852CV Double Row Full Complement Cylindrical Roller Bearing 260x320x60mm
SKF NNCL4852CV Double Row Full Complement Cylindrical Roller Bearing 260x320x60mm
Out of stock
Share this product
Description
Description
|
SKF NNCF Series Double Row Full Complement Cylindrical Roller Bearings: Have integral locating flanges on the inner race and one on the outer raceway serving to permit axial location in one direction, a retaining ring is fitted opposite the integral flange to maintain the assembly. They can tolerate axial loads in one direction. Benefits: Tolerate axial load in one direction, none separable construction |
- Brand / Quality:
- SKF - High Quality
- Inside Diameter:
- 260mm
- Outside Diameter:
- 320mm
- Width:
- 60mm
- Seals / Shields:
- None
- Clearance:
- * Standard
Technical
Technical
| d | 260mm |
|---|---|
| D | 320mm |
| B | 60mm |
| Dynamic load C | 561 Kn |
| Static load Co | 1400 Kn |
| Fatigue load limit Pu | 132 Kn |
| Reference speed | 800 rpm |
| Limiting speed | 1000 rpm |
| Weight | 10.6 kg |
| d1 | 283mm |
| E | 304.2mm |
| b1 | 8mm |
| K | 4mm |
| r1r2 min | 2mm |
| S | 4mm |
| da min | 270mm |
| Da max | 310mm |
| Ra max | 2mm |
