• SS20DP/15B-0.375 Imperial EN8 Steel Spur Gear 15 Tooth 20 DP Bored 0.375 inch (H8)
1 1

SKU: SS20DP/15B-0.375_INCH

SS20DP/15B-0.375 Imperial EN8 Steel Spur Gear 15 Tooth 20 DP Bored 0.375 inch (H8)

SS20DP/15B-0.375 Imperial EN8 Steel Spur Gear 15 Tooth 20 DP Bored 0.375 inch (H8)
€45,65 ex VAT
€45,65 ex VAT
Sale Sold out

In stock

Price Break
5+ €34,70
9+ €32,75
19+ €32,36
29+ €31,97
49+ €31,58
74+ €31,19
99+ €29,24
199+ €28,85
249+ €28,46
499+ €28,07
999+ €27,29

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
GEAR_IMP_S_DESC
Brand / Quality:
Drive-Flex - High Quality
Bore:
9.53mm = 0.375 (3/8) inch
Number of Teeth:
15
Variant:
Tooth Profile B
Pitch Circle Diameter:
19.05mm = 0.75 (3/4) inch
Gear Modulus:
20DP
Technical
Number of Teeth 15
Pitch (dp) 0.75 inch
Bore (H8) 0.375 inch
Hub / Boss (dm) 0.56 inch
Outside (de) 0.85 inch
Width (A) 0.75 inch
Face Width (B) 0.375 inch
Modulus / Diametral Pitch DP 20 dp
Tolerance unless otherwise stated +- 0.01 inch
Pressure Angle 20 degrees
