• SS20DP/50B-0.5 Imperial EN8 Steel Spur Gear 50 Tooth 20 DP Bored 0.5 inch (H8)
1 1

SKU: SS20DP/50B-0.5_INCH

SS20DP/50B-0.5 Imperial EN8 Steel Spur Gear 50 Tooth 20 DP Bored 0.5 inch (H8)

SS20DP/50B-0.5 Imperial EN8 Steel Spur Gear 50 Tooth 20 DP Bored 0.5 inch (H8)
€82,18 ex VAT
€82,18 ex VAT
Sale Sold out

In stock

Price Break
5+ €62,45
9+ €58,94
19+ €58,24
29+ €57,54
49+ €56,84
74+ €56,14
99+ €52,63
199+ €51,93
249+ €51,23
499+ €50,52
999+ €49,12

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More
Description
GEAR_IMP_S_DESC
Brand / Quality:
Drive-Flex - High Quality
Bore:
12.7mm = 0.5 (1/2) inch
Number of Teeth:
50
Variant:
Tooth Profile B
Pitch Circle Diameter:
63.5mm = 2.5 (2-1/2) inch
Gear Modulus:
20DP
Technical
Number of Teeth 50
Pitch (dp) 2.5 inch
Bore (H8) 0.5 inch
Hub / Boss (dm) 1 inch
Outside (de) 2.6 inch
Width (A) 1 inch
Face Width (B) 0.375 inch
Modulus / Diametral Pitch DP 20 dp
Tolerance unless otherwise stated +- 0.01 inch
Pressure Angle 20 degrees
