SKU: SSUCT.202
SSUCT202 Metric Stainless Steel Take Up Unit Housing with 15mm Bore Stainless Insert
- Regular price
- €64.72 ex VAT
- Sale price
- €64,72
- Regular price
-
Not in stock
Quantity Price Breaks
3
€57.60
4
€54.36
9
€53.72
19
€53.07
49
€52.42
99
€51.78
499
€48.54
999
€47.89
1999
€47.25
2999
€46.60
4999
€45.30
SKU:
SSUCT.202
SSUCT202 Metric Stainless Steel Take Up Unit Housing with 15mm Bore Stainless Insert
- Regular price
- €64.72 ex VAT
- Sale price
- €64,72
- Regular price
-
Description
|
SSUCT or ST Series Stainless Steel Take up Units: Supplied with a fully sealed stainless steel bearing insert fitted in the stainless steel housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing, food safe and approved, exceptionally strong and durable Note: These bearings will eventually corrode in a marine environment and it is recommended to completely cover with grease or similar protection where practical. Due to the material requirements of these bearings to have a hard-wearing construction, they will be made of a harder form of Stainless Steel, such as 440 or similar, which will be attracted by magnets. Quotations for non-magnetic versions are available upon request. |
Technical
| d | = | 15mm |
| o | = | 16mm |
| g | = | 10mm |
| p | = | 51mm |
| q | = | 32mm |
| s | = | 19mm |
| b | = | 51mm |
| K | = | 12mm |
| e | = | 76mm |
| a | = | 89mm |
| w | = | 94mm |
| j | = | 32mm |
| l | = | 21mm |
| h | = | 61mm |
| Bi | = | 31mm |
| n | = | 12.7mm |
| Weight | = | 0.79 kg |
| Dynamic load | = | 1000 kgf |
| Static load | = | 630 kgf |
