SKU: TBS-D-08B-23

23 Tooth 08B Duplex Sprocket Tapered Locking Bush Type for 1/2 inch Pitch Chain (Bush not Incl.)

€19.49 ex VAT
€19,49
ex VAT
Equivalent to: TS42-23 08B2 TS41-23 41-23
Not in stock

Quantity Price Breaks

5 €17.35
9 €16.37
19 €16.18
29 €15.98
49 €15.79
74 €15.59
99 €14.62
199 €14.42
249 €14.23
499 €14.03
999 €13.64
Return policy
90-Days Free Returns
Learn More
Low cost shipping
International Delivery
Learn More
23 Tooth 08B Duplex Sprocket Tapered Locking Bush Type for 1/2 inch Pitch Chain (Bush not Incl.)
23 Tooth 08B Duplex Sprocket Tapered Locking Bush Type for 1/2 inch Pitch Chain (Bush not Incl.)
23 Tooth 08B Duplex Sprocket Tapered Locking Bush Type for 1/2 inch Pitch Chain (Bush not Incl.)
23 Tooth 08B Duplex Sprocket Tapered Locking Bush Type for 1/2 inch Pitch Chain (Bush not Incl.)
SKU: TBS-D-08B-23

23 Tooth 08B Duplex Sprocket Tapered Locking Bush Type for 1/2 inch Pitch Chain (Bush not Incl.)

€19.49 ex VAT
€19,49
ex VAT

Description

Tapered Bore Sprockets: Small sprockets are usually manufactured from C45 Steel and the large sprockets maybe supplied in G22 Cast Iron. These taper bore sprockets accept tapered locking bushes in a wide variety of shaft sizes to allow the end user to easily fit the sprocket to the shaft with minimal effort and no machining.
Available in a comprehensive range of British Standard Simplex, Duplex and Triplex sizes. Pilot Bore variants available if required.
Benefits: Universal on the shelf stock - wide range of tapered locking bushes and shaft sizes available to choose from. Durable and hard-wearing.

Technical

Tooth Radius r3 = 13mm
Chamfer c = 1.3mm
Tooth Width b1 = 7mm
Tooth Width B1 = 7.2mm
Tooth Width B2 = 21mm
Tooth Width B3 = 34.9mm
Pitch = 12.7mm
Width Between Inner = 7.75mm
Roller Diameter = 8.51mm
No. of Teeth = 23
Outer Diameter de = 98.2mm
Pitch Diameter dp = 93.27mm
Hub Diameter dm = 79mm
Length Through Bore A = 25mm
Reference = 42-23
Taper Bush = <
a href=advanced_search_result.php?sort=2a& = search_in_description=1&
keywords=1610+tapered+locking+bush> = 1610 Click Here<
/a> =
