SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in

Name: SKF TMHP Hydraulically Assisted Heavy Duty Jaw Pullers 290-500mm / 11.4-19.7in
Brand: SKF
SKU: TMHP30/170-SKF
Price: 8367.00 EUR
Availability: InStock

€8.367,00 ex VAT

Sale Sold out

In stock

Price Break

10+ €6.358,52

19+ €6.287,08

29+ €6.215,63

39+ €6.144,19

49+ €6.072,75

74+ €6.001,30

99+ €5.929,86

199+ €5.858,41

249+ €5.786,97

499+ €5.715,53

999+ €5.644,08

Return policy

90-Days Free Returns

Learn More

Low cost shipping

International Delivery

Learn More

Description

SKF Hydraulically Assisted Heavy Duty Jaw Pullers TMHP Series: The SKF hydraulically-assisted pullers TMHP 15, TMHP 30 and TMHP 50 provide new combined forces of puller power and safety. They are self-centring pullers for the occasions when large forces are inevitable. Pantograph system for ultimate alignment of withdrawal forces and minimised risk of damaging shaft or bearing.
Benefits: Extreme forces applied with ease (self-centring, lifting handle, eye bolt, etc.)

Brand / Quality:: SKF - High Quality

Technical

Width of Grip	290-500mm (11.4-19.7 in.)
Effective Length of Arms	170mm (6.7 in.)
Claw Height	35mm (1.4 in.)
Stroke	50mm (2 in.)
Maximum Working Pressure Hydraulic Cylinder	80 Mpa (11 600 psi)
Maximum Withdrawal Force	300 kN (34 US ton)
