SKU: UCFC211D1-NTN
NTN UCFC211D1 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert - Allow 2-3 Days
- Regular price
- €69.94 ex VAT
- Sale price
- €69,94
- Regular price
-
Not in stock
Quantity Price Breaks
3
€62.25
4
€58.75
9
€58.05
19
€57.35
49
€56.65
99
€55.95
499
€52.46
999
€51.76
1999
€51.06
2999
€50.36
4999
€48.96
SKU:
UCFC211D1-NTN
NTN UCFC211D1 Metric Four Bolt Cast Iron Round Flanged Housing with 55mm Insert - Allow 2-3 Days
- Regular price
- €69.94 ex VAT
- Sale price
- €69,94
- Regular price
-
Description
|
UCFC Series 4 Bolt Round Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the round cast iron housing and includes a grease nipple to facilitate re-lubrication, this style has the benefit of a shouldered back face to facilitate location of the housing prior to fastening in place. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 55mm |
| L | = | 185mm |
| J | = | 150mm |
| (J< | = | sub> |
| 1< | = | /sub> |
| ) | = | 106.1mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 13mm | |
| N | = | 19mm |
| A< | = | sub> |
| 3< | = | /sub> |
| = | 12mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 31mm | |
| A | = | 43mm |
| H< | = | sub> |
| 3< | = | /sub> |
| = | 125mm | |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 58.4mm | |
| B | = | 55.6mm |
| S | = | 22.2mm |
| Fixing bolt | = | M16 |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 48 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 29.2 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 2.29 kN | |
| --- | = | Unit information |
| Mass | = | 4 kg |
