SKU: UCFX10D1-NTN
NTN UCFX10D1 Metric Four Bolt Square Cast Iron Flange Housing with 50mm Bore Insert
- Regular price
- €59.95 ex VAT
- Sale price
- €59,95
- Regular price
-
ex VAT
In stock
Quantity Price Breaks
3
€53.36
4
€50.36
9
€49.76
19
€49.16
49
€48.56
99
€47.96
499
€44.96
999
€44.36
1999
€43.76
2999
€43.16
4999
€41.97
Description
|
UCFX or MSF Series 4 Bolt Square Cast Iron Housings: Bearing unit supplied with a fully sealed bearing insert fitted in the cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required Benefits: Cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing |
Technical
| --- | = | Dimensions |
| Shaft diameter | = | 50mm |
| L | = | 162mm |
| J | = | 130mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 26mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 20mm | |
| A | = | 44mm |
| N | = | 19mm |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 59.4mm | |
| B | = | 55.6mm |
| S | = | 22.2mm |
| Fixing bolt | = | M16 |
| --- | = | Load rating |
| Dynamic load C< | = | sub> |
| r< | = | /sub> |
| = | 48 kN | |
| Static load C< | = | sub> |
| 0r< | = | /sub> |
| = | 29.2 kN | |
| Fatigue load limit C< | = | sub> |
| u< | = | /sub> |
| = | 2.29 kN | |
| --- | = | Unit information |
| Mass | = | 3.8 kg |
