SKU: UCT.212.TS.CHAL
Challenge / FK UCT212 Metric Cast Iron Take Up Unit Housing with 60mm Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
- Regular price
- €139.20 ex VAT
- Sale price
- €139,20
- Regular price
-
Quantity Price Breaks
Challenge / FK UCT212 Metric Cast Iron Take Up Unit Housing with 60mm Bore Insert and Triple Lip Seal Ideal for Agricultural and Outdoor Use
- Regular price
- €139.20 ex VAT
- Sale price
- €139,20
- Regular price
-
Description
UCT Cast Iron Take Up Unit Housing: These normal-duty bearing units are fitted with a triple lip seal in a cast iron housing and includes a grease nipple to facilitate re-lubrication. These bearings are perfect for agricultural applications where the bearings are exposed to contamination. The bearing insert has 2 grub screws to allow tightening against the shaft once fitted. The inserts (available separately) can be removed from the housings for future replacement as required.
Benefits: High tolerance to harsh environments, cost effective bearing / housing assembly, re-lubricatable, replaceable insert, grub screw fixing
Technical
| Shaft Diameter d | = | 60mm |
| Nut Slot Width o | = | 32mm |
| Distance g | = | 19mm |
| Dimention p | = | 102mm |
| Dimention q | = | 64mm |
| Hole s | = | 35mm |
| Dimention b | = | 102mm |
| Slot Width k | = | 22mm |
| Distance Between Slots e | = | 130mm |
| Overall Casting Depth a | = | 146mm |
| Width w | = | 194mm |
| Diameter j | = | 64mm |
| Casting Width at Slots l | = | 46mm |
| Dimension h | = | 119mm |
| Grub Screws x 2 | = | M10x1.25 |
| Load Rating (Dynamic) | = | 4100kg |
| Load Rating (Static) | = | 3150kg |
| Max Speed | = | 1500 rev/min |
| Grease Nipple Thread Size | = | M8 |
| Working Temperature | = | -30& |
| deg | = | C to +120& |
| deg | = | C |
| Insert No | = | UC212 |
| Housing No | = | T212 |
