SKU: UELFC211-200D1W3-NTN
NTN UELFC211-200D1W3 Imperial Four Bolt Cast Iron Round Flanged Housing with 2 inch Eccentric Collar Insert - Allow 2-3 Days
NTN UELFC211-200D1W3 Imperial Four Bolt Cast Iron Round Flanged Housing with 2 inch Eccentric Collar Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UELFC200 Series 4 Bolt Cast Iron Round Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the round cast iron housing and include a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar with a grub screw to facilitate securing the bearing to the shaft after installation. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar/grub screw fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 50.8mm = 2 Inch
- Style:
- UELFC
- Pitch Circle Diameter:
- 4-11/64 inch
Technical
Technical
| Shaft diameter | 2 inch |
|---|---|
| L | 7-9/32 inch |
| J | 5-29/32 inch |
| (J<sub>1</sub> | 4-11/64 inch |
| A<sub>2</sub> | 33/64 inch |
| N | 3/4 inch |
| A<sub>3</sub> | 15/32 inch |
| A<sub>1</sub> | 1-7/32 inch |
| A | 1-11/16 inch |
| H<sub>3</sub> | 4.9213 inch |
| A<sub>0</sub> | 2-45/64 inch |
| B<sub>1</sub> | 2.811 inch |
| S | 1.093 inch |
| F min. | 2-15/16 inch |
| Fixing bolt | 5/8 inch |
| Mass | 9.5 lbs |
