NTN UELFL208-108D1 Imperial Two Bolt Cast Iron Oval Housing with 1-1/2 inch Bore Eccentric Collar Insert - Allow 2-3 Days
NTN UELFL208-108D1 Imperial Two Bolt Cast Iron Oval Housing with 1-1/2 inch Bore Eccentric Collar Insert - Allow 2-3 Days
Out of stock
Share this product
Description
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
- Brand / Quality:
- NTN - High Quality
- Inside Diameter:
- 38.1mm = 1.5 (1-1/2) inch
- Style:
- UELFL
- Bolt Hole Centres:
- 5-43/64 inch
Technical
Technical
| Shaft diameter | 1-1/2 inch |
|---|---|
| H | 6-7/8 inch |
| J | 5-43/64 inch |
| A<sub>2</sub> | 53/64 inch |
| A<sub>1</sub> | 19/32 inch |
| A | 1-13/32 inch |
| N | 5/8 inch |
| L | 3-15/16 inch |
| A<sub>0</sub> | 2-13/64 inch |
| B<sub>1</sub> | 2.217 inch |
| S | 0.843 inch |
| F min. | 2-1/4 inch |
| Fixing bolt | 1/2 inch |
| Mass | 3.5 lbs |
