SKU: UELFL209D1W3-NTN
NTN UELFL209D1W3 Metric Two Bolt Cast Iron Oval Housing with 45mm Bore Eccentric Collar Insert - Allow 2-3 Days
- Regular price
- €54.50 ex VAT
- Sale price
- €54,50
- Regular price
-
Not in stock
Quantity Price Breaks
3
€48.51
4
€45.78
9
€45.24
19
€44.69
49
€44.15
99
€43.60
499
€40.88
999
€40.33
1999
€39.79
2999
€39.24
4999
€38.15
SKU:
UELFL209D1W3-NTN
NTN UELFL209D1W3 Metric Two Bolt Cast Iron Oval Housing with 45mm Bore Eccentric Collar Insert - Allow 2-3 Days
- Regular price
- €54.50 ex VAT
- Sale price
- €54,50
- Regular price
-
Description
UELFL200 Series 2 Bolt Cast Iron Oval Housings: These bearing units are supplied with a fully sealed bearing insert fitted in the oval cast iron housing and includes a grease nipple to facilitate re-lubrication. The bearing insert has an eccentric collar to allow tightening against the shaft once fitted. The inserts can be removed from the housings for future replacement as required.
Benefits: Can be re-lubricated, replaceable bearing insert, eccentric collar fixing
Technical
| Shaft diameter | = | 45mm |
| H | = | 188mm |
| J | = | 148mm |
| A< | = | sub> |
| 2< | = | /sub> |
| = | 22mm | |
| A< | = | sub> |
| 1< | = | /sub> |
| = | 16mm | |
| A | = | 38mm |
| N | = | 19mm |
| L | = | 108mm |
| A< | = | sub> |
| 0< | = | /sub> |
| = | 56.9mm | |
| B< | = | sub> |
| 1< | = | /sub> |
| = | 56.3mm | |
| S | = | 21.4mm |
| F min. | = | 62mm |
| Fixing bolt | = | M16 |
| Mass | = | 2 kg |
